New arrival PCB LED heat resistant thermal conductive silicone pad

FOB Reference Price:Get Latest Price
$0.01 - $0.50 / Pieces | 100 Piece/Pieces (Min. Order)
Customization:
shape (Min. Order: 100 Pieces)
size (Min. Order: 100 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
sheen
Model Number:
SF500G
Type:
Insulation Sheet
Material:
Silicone
Application:
LED industrial/cell phone industrial/computer pc industry, etc
Rated Voltage:
>200VAC/mil
Tensile Strength:
45 psi
Thickness(inch/mm):
0.3-10mm
Hardness, (Shore A):
70±5
Tensile Strength, (psi):
45psi
Thermal Conductivity,(W/m-K):
3.5
Continuous Use Temp,(°F/℃):
-58 to 392 °F , -50 to 200 ℃
Breakdown Voltage, (V):
>2500(thickness)≤0.02inch >4500(thickness)≥0.03inch
Dielectric Constant, (1M HZ):
5.6
Flame Rating:
94 V0
Density, (g/cc):
3.0
Color:
Yellow,Blue,Pink
Supply Ability
Supply Ability:
2000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
New arrival PCB LED heat resistant thermal conductive silicone pad
Packing: plastic bag in carton
Port
shenzhen
Product Description
Product Information



Product Name
thermal conductive silicone pad
Item No.SF500GTest Method
ColorYellow,Pink,BlueVisual

Main ingredients

Silicone
Thickness (inch/mm)0.3-10mmASTM D751
Density(g/cc)
3.0g/ccASTM D297
Hardness(shore A)70±5ASTM D2240
Tensile Strength
45psiASTM D412
Fire Rating
UL94 V0 Equivalent UL
Breakdown voltage(V)

>2500(Thickness≥0.02″)

>4500(Thickness≥0.03″)

ASTM D149
Volume Resistivity
(TΩ.cm)
2.0 X 1013
ASTM D257
Dielectric Constant (1M HZ)5.6 ASTM D150
Thermal Conductivity (W/m k)3.5ASTM D5470
Service Temperature

-58 to 392 °F

-50oC ~ 200oC

 ***
IntroductionThe SF500G products are mostly used for heat sink, microprocessors and other power consumption semiconductors. This type of adhesive tape possesses ultimate bonding strength with low thermal impedance, with which in effect can be able to replace the method of lubricating grease and mechanical fixing. the method of lubricating grease and mechanical fixing.
Features and Benefits3.5 W/m-K Thermal Conductivity High bond strength to a variety of surfaces Double sided pressure sensitive adhesive tape High performance, thermally conductive acrylic Adhesive Withstand heat variation long term
Typical Applications Include-LED lighting
-Cooling Components to the Chassis, Frame,
or other type of heat spreader
- Mass Storage Drives
- Heat Pipe assemblies
- RDRAM Memory Moduies
- High Frequency Microprocessors
- Notebook and Desktop PCs



Product Display





Hot Sale

Thermally conductive
pad >
Thermally conductive
tape >
Thermal silicone RTV >Thermal grease >
Phase change thermal
interface materials >
Thermally conductive
silicone pug >
Thermally conductive
insulators >
Thermally conductive
graphite sheets >
Thermally double
component silicone >
Thermally conductive
plastics >
Epoxy adhesive >More products >

Product Advantage

  • Fill the air gap between heating devices and heat sink or metal base

  • Improve the efficiency and service life of heating components

  • Ultra-strong adhesion to various surface

  • High thermally conductive acrylic adhesive

  • Double-sided pressure-sensitive adhesive tape

  • Effectively replace lubricating grease and mechanical fastening

  • With good adhesion to most metal, glass, alloy and plastic materials, etc.

  • Solidified under room temperature

  • With good electrical insulation and weather resistance

  • No preheating process is required for the product

  • Excellent adhesion and sealing strength with good conductivity

  • Suitable for auto-dispensing and screen printing



Compared with traditional materials, the phase change thermal interface materials can cover and fill the gap and hollow between the contact interfaces when being liquid.
